Large PSA Oxygen Generator Plant For Hospital Portable

PSA Oxygen Generator

Description

PSA ( Pressure Swing Adsorption) Technology a revolution in Non Cryogenic Air Separation and Oxygen Generation Technology uses
special grade of ZMS ( Zeolite Molecular Sieve).

The compressed air is passed through a Twin Tower PSA module interconnected with automatic change over valves. After passing
through a Refrigerated Dryer air gets dried. Dried compressed air will now come in contact with bed of Zeolite molecular sieves
(ZMS). Zeolite Molecular Sieves are special grade of adsorbent which have the property of preferential adsorption of nitrogen
molecules. At a time one tower remains under nitrogen production cycle, whereas the other tower undergoes regeneration which is
achieved through depressurization of the tower to atmospheric pressure. The outgoing oxygen gas is sent to a surge vessel where
the minimum pressure will be maintained with the help of Back pressure Regulator.

Advantages
1.Simple installation and maintenance thanks to modular design and construction.
2.Fully automated system for simple and reliable operation.
3.Guaranteed availability of high-purity industrial gases.
4.Guaranteed by the availability of product in liquid phase to be stored for use during any maintenance operations.
5.Low energy consumption.
6.Short time delivery.
